Approval | CE  cULus Listed  |
Purpose of U1 | Module supply  |
Supply voltage (V) | 24 Â V |
Type of supply voltage U1 | DC Â |
Power consumption DC | 3 Â W |
Fieldbus interface | CANopen  |
Fieldbus device type | Slave  |
Name of fieldbus protocol | CiA 301 V4.2.0 Â |
Perm. fieldbus station address | 0 - 99d  |
Selectable transmission rates | 10 kBit/s  500 kBit/s  20 kBit/s  250 kBit/s  1 MBit/s  800 kBit/s  50 kBit/s  125 kBit/s  |
Connection fieldbus | 9-pin D-Sub male connector  |
Galv. isolation fieldbus | Yes  |
Type of galvanic isolation | Functional insulation  |
Number of MODBUS interfaces | 8 Â |
Modbus connection | RJ45 Â |
Modbus device type | Server  |
Modbus operating modes | Auto-MDIX  Autonegotiation  |
Modbus selectable trans. rate | 10 MBit/s  100 MBit/s  |
Galv. isolation from Modbus | Yes  |
Ambient temperature standard | EN 60068-2-14 Â |
Ambient temperature | 0 - 60  °C |
Storage temperature standard | EN 60068-2-1/-2 Â |
Climatic suitability standard | EN 60068-2-30 Â EN 60068-2-78 Â |
Humidity rating | 93 % r. h. at 40 °C  |
Condensation permitted? | Not permitted  |
Perm. operating height ASL | 2000 m  |
EMC to standard ... | EN 61131-2 Â |
Vibration to standard ... | EN 60068-2-6 Â |
Acc. shock to standard1 | 15g  |
Clearance & creepage dist. to | EN 61131-2 Â |
Overvoltage category | II Â |
Pollution degree clear.&creep. | 2 Â |
Protection type standard | ENÂ 60529 Â |
Protection type, mounting | Â |
Protection type, housing | Â |
Terminal protection type | Â |
Potential isolation 1 between | CANopen and system voltage  |
Type of potential isolation 1 | Functional insulation  |
Potential isolation 2 between | Modbus and system voltage  |
Type of potential isolation 2 | Functional insulation  |
DIN-rail dimensions | 35 x 7.5 EN 50022 Â |
Housing material lower section | PC Â |
Housing material front plate | PC Â |
Connection terminal | Screw terminal plug-in  Spring-loaded terminal, plugin  |
Flex. cond. c/s AWG info | 24 - 12 AWG Â |
Height dimension | 96 Â mm |
Width dimension | 22.5 Â mm |
Depth dimension | 114.3 Â mm |
Net weight | 90 Â g |
Gross weight | 110 Â g |
RoHS conformity | yes  |
REACh compliance | Contains no SVHC substances  |
WEEE classifikation (08/2018) | 6 small IT-/communic. device  |
ECLASS version | ECLASS-9.1 Â |
ECLASS Reference Feature | 27242208 Â |
ETIM Version | ETIM-7.0 Â |
ETIM Reference Group | EG000024Â Â |
