312043
PSSu, head module, decentralised system PSSuniversal I/O, failsafe and standard, PL e, SIL CL 3, 2 RJ45 Ports, PROFINET IO DEVICE, with PROFIsafe profile, IRT/RT, MRP, Shared Device, iPar Server, PROFIenergy.
||
-
-
Secure Shopping
100% Money Back Guarantee.
-
30-DAY RETURNS
30 Days After-sales Return.
-
Worldwide Delivery
Worldwidely Fast Shipping.
General data
| Approval | CE  cULus Listed  EAC (Eurasian)  TÜV  |
| Application range | Standard/failsafe  |
Â
Technical data
PROFINET interface
| Settable trans.rate PROFINET | 100 MBit/s  |
| Trans. rate setting PROFINET | Automatic  |
| PROFINET certification | PNO Â |
| PROFINET manufacturer ID | 092Fh  |
| Connector type PROFINET i/f | RJ45 Â |
| PROFINET type | Slave  |
Environmental data
| Climatic suitability to ... | EN 60068-2-30 Â EN 60068-2-2 Â EN 60068-2-1 Â EN 60068-2-78 Â EN 60068-2-14 Â |
| Ambient temperature | 0 - 60  °C |
| Climatic suitability standard | EN 60068-2-78 Â |
| Humidity rating | 93 % r. h. at 40 °C  |
| Condensation permitted? | Not permitted  |
| Perm. operating height ASL | 2000 m  |
| EMC to standard ... | EN 61000-6-2 Â EN 61000-4-4 Â EN 61000-4-5 Â EN 61000-6-4 Â EN 61000-4-6 Â EN 61000-4-2 Â EN 61000-4-3 Â |
| Vibration to standard ... | EN 60068-2-6 Â |
| Acc. shock to standard1 | 15g  |
| Acc. shock to standard2 | 25g  |
| Clearance & creepage dist. to | EN 60664-1 Â |
| Overvoltage category | II Â |
| Pollution degree clear.&creep. | 2 Â |
| Protection type, mounting | Â |
| Protection type, housing | Â |
Mechanical data
| Housing material lower section | PC Â |
| Housing material front plate | PC Â |
| Height dimension | 128.4 Â mm |
| Width dimension | 75.2 Â mm |
| Depth dimension | 79.4 Â mm |
| Net weight | 170 Â g |
| Gross weight | 235 Â g |
Environment
| REACh compliance | contains min. 1 SVHC-substance  |
| WEEE classifikation (08/2018) | 5 devices (feed size < 50cm> |
Commercial data
| ECLASS version | ECLASS-9.1 Â |
| ECLASS Reference Feature | 27242608 Â |
| ETIM Version | ETIM-7.0 Â |
| ETIM Reference Group | EG000024Â Â |
