312265
PSSu, electronic module, failsafe, analogue inputs and outputs, 1 input,- - 10.24 - 10.23 V, dual-pole, differential input, resolution 13 Bit.
||
-
-
Secure Shopping
100% Money Back Guarantee.
-
30-DAY RETURNS
30 Days After-sales Return.
-
Worldwide Delivery
Worldwidely Fast Shipping.
General data
| Approval | CE  cULus Listed  KOSHA  EAC (Eurasian)  TÜV  |
| Application range | Failsafe  |
Â
Technical data
Analog inputs
| Number of analogue inputs | 1 Â |
| Type of analogue inputs | Voltage  |
| Signal range analog input | -10.24 V +10.2375 V Â |
| Type of input filter | RC filter  |
| Value least signif. bit U-Me | 2.5 mV Â |
| Resolution of analogue inputs | 13 Â Bit |
| Conversion method analog i/p | Successive approximation  |
| Pot. isolation analog inp./ | Yes  |
Inputs
| Potential isolation inputs | yes  |
Environmental data
| Climatic suitability to ... | EN 60068-2-30 Â EN 60068-2-2 Â EN 60068-2-1 Â EN 60068-2-78 Â EN 60068-2-14 Â |
| Ambient temperature standard | EN 60068-2-14 Â |
| Ambient temperature | 0 - 60  °C |
| Storage temperature standard | EN 60068-2-1/-2 Â |
| Climatic suitability standard | EN 60068-2-30 Â EN 60068-2-78 Â |
| Humidity rating | 93 % r. h. at 40 °C  |
| Condensation permitted? | Not permitted  |
| Perm. operating height ASL | 2000 m  |
| EMC to standard ... | EN 61000-6-2 Â EN 61000-4-4 Â EN 61000-4-5 Â EN 61000-6-4 Â EN 61000-4-6 Â EN 61000-4-2 Â EN 61000-4-3 Â |
| Vibration to standard ... | EN 60068-2-6 Â |
| Acc. shock to standard1 | 15g  |
| Clearance & creepage dist. to | IEC 60664-1 Â |
| Overvoltage category | II Â |
| Pollution degree clear.&creep. | 2 Â |
| Protection type standard | ENÂ 60529 Â |
| Protection type, mounting | Â |
| Protection type, housing | Â |
| Terminal protection type | Â |
Mechanical data
| Housing material lower section | PC Â |
| Housing material front plate | PC Â |
| Housing material code | PA Â |
| Terminal style | plug-in  |
| Height dimension | 76 Â mm |
| Width dimension | 12.6 Â mm |
| Depth dimension | 60.2 Â mm |
| Net weight | 35 Â g |
| Gross weight | 44 Â g |
| Name of coding element | M Â |
| Colour of coding element | Yellow |
Environment
| WEEE classifikation (08/2018) | 5 devices (feed size < 50cm> |
Commercial data
| ECLASS version | ECLASS-9.1 Â |
| ECLASS Reference Feature | 27242601 Â |
| ETIM Version | ETIM-7.0 Â |
| ETIM Reference Group | EG000024Â Â |
