    PILZ

    312275 PILZ


    left swipe Rotate image right swipe

    Out Of Stock

    312275

    PSSu, electronic module, failsafe, counter, 1 input, absolute encoder SSI encoder, differential signal RS422, resolution 32 Bit, 7 transmission rates, 62.6 - 1500 kHz.

    ACCESSORIES

    ||

    PILZ

    5.00 10

    10 Review(s)
    $712.15 $593.46 / each
    166207
    312275
    PILZ
    FACTORY SEALED
    312275.pdf

    • Quality Assurance

      OEM Quality Spare Parts.

    • Secure Shopping

      100% Money Back Guarantee.

    • 30-DAY RETURNS

      30 Days After-sales Return.

    • Worldwide Delivery

      Worldwidely Fast Shipping.

    ApprovalCE
    cULus Listed
    KOSHA
    EAC (Eurasian)
    TÜV
    Application rangeFailsafe

    Technical data
    No. of inputs absolute encoder1
    Signal clock output ABSDifferential signal (RS 422)
    Signal data input ABSDifferential signal (RS 422)
    Potent. isol. ABS/per. supplyYes
    Potent. isol. ABS/mod. supplyYes
    Climatic suitability to ...EN 60068-2-30
    EN 60068-2-2
    EN 60068-2-1
    EN 60068-2-78
    EN 60068-2-14
    Ambient temperature standardEN 60068-2-14
    Ambient temperature0 - 60  °C
    Storage temperature standardEN 60068-2-1/-2
    Climatic suitability standardEN 60068-2-30
    EN 60068-2-78
    Humidity rating93 % r. h. at 40 °C
    Condensation permitted?Not permitted
    Perm. operating height ASL2000 m
    EMC to standard ...EN 61000-6-2
    EN 61000-4-4
    EN 61000-4-5
    EN 61000-4-6
    EN 61000-6-4
    EN 61000-4-2
    EN 61000-4-3
    Vibration to standard ...EN 60068-2-6
    Acc. shock to standard115g
    Acc. shock to standard2
    Clearance & creepage dist. toEN 60664-1
    Overvoltage categoryII
    Pollution degree clear.&creep.2
    Protection type standardEN 60529
    Protection type, mounting
    Protection type, housing
    Terminal protection type
    Housing material lower sectionPC
    Housing material front platePC
    Housing material codePA
    Terminal styleplug-in
    Height dimension76  mm
    Width dimension12.6  mm
    Depth dimension60.2  mm
    Net weight35  g
    Gross weight43  g
    Name of coding elementJ
    Colour of coding elementYellow
    REACh compliancecontains min. 1 SVHC-substance
    WEEE classifikation (08/2018)5 devices (feed size < 50cm>
    ECLASS versionECLASS-9.1
    ECLASS Reference Feature27242604
    ETIM VersionETIM-7.0
    ETIM Reference GroupEG000024
