314225
PSSu, electronic module, failsafe, digital inputs and outputs, 2outputs, relay contacts, 8 A, N/O, potential-free, for increased environmental requirements.
||
-
-
Secure Shopping
100% Money Back Guarantee.
-
30-DAY RETURNS
30 Days After-sales Return.
-
Worldwide Delivery
Worldwidely Fast Shipping.
General data
| Approval | CE  cULus Listed  KOSHA  EAC (Eurasian)  TÜV  |
| Application range | Failsafe  |
Â
Technical data
Electrical data
| Permitted loads | Resistive  Inductive  |
Relay outputs
| Number of relay outputs | 2 Â |
| Utilisation cat. AC/DC1 stand. | EN 60947-4-1 Â |
| Voltage AC1 safety cont. | 250 Â V |
| Max. current AC1 safety cont. | 8 Â A |
| Voltage DC1 safety cont. | 24 Â V |
| Max. current DC1 safety cont. | 8 Â A |
| Utilisation cat. AC15/DC13sta. | EN 60947-5-1 Â |
| Voltage AC15 safety cont. | 230 Â V |
| Max. current AC15 safety cont. | 3 Â A |
| Voltage DC13 safety cont. | 24 Â V |
| Safety contacts: AC at UL | 250 VAC G.U. (same polarity) Â |
| Safety contacts: pilot duty | B300, R300 Â |
| Typ. process time relay o/p ON | 20 - 60 ms  |
| Relay contact material | AgCuNi  |
| Addit. contact details relay | + 0.2 µm Au  |
| Pot.isol. RlCont - Uint1 | 4900 V (safe separation) Â |
| Pot.isol. RlCont to U2 | 4900 V (safe separation) Â |
| Pot.isol. RlCont1 to CRail | 3050 V (basic insulation) Â |
| Pot.isol. RlCont1 to RlCont2 | 4900 V (safe separation) Â |
Environmental data
| Climatic suitability to ... | EN 60068-2-30 Â EN 60068-2-2 Â EN 60068-2-1 Â EN 60068-2-78 Â EN 60068-2-14 Â |
| Ambient temperature standard | EN 60068-2-14 Â |
| Ambient temperature | -40 - 70  °C |
| Ambient temp. with UL | 60 °C  |
| Storage temperature standard | EN 60068-2-1/-2 Â |
| Climatic suitability standard | EN 60068-2-78 Â |
| Humidity rating | 93 % r. h. at 40 °C  |
| Condensation permitted? | at prot. xtra low volt.: brief  |
| Perm. operating height ASL | 2000 m  |
| EMC to standard ... | EN 61000-6-2 Â EN 61000-4-4 Â EN 61000-4-5 Â EN 61000-6-4 Â EN 61000-4-6 Â EN 61000-4-2 Â EN 61000-4-3 Â |
| Vibration to standard ... | EN 60068-2-6 Â |
| Broad band noise to | EN 60068-2-64 Â |
| Acc. shock to standard1 | 15g  |
| Acc. shock to standard2 | Â |
| Clearance & creepage dist. to | EN 60664-1 Â |
| Overvoltage category | III Â |
| Pollution degree clear.&creep. | 2 Â |
| Protection type standard | ENÂ 60529 Â |
| Protection type, mounting | Â |
| Protection type, housing | Â |
| Terminal protection type | Â |
Mechanical data
| Housing material lower section | PC Â |
| Housing material front plate | PC Â |
| Housing material code | PA Â |
| Terminal style | plug-in  |
| Height dimension | 76 Â mm |
| Width dimension | 25.2 Â mm |
| Depth dimension | 60.2 Â mm |
| Net weight | 91 Â g |
| Gross weight | 100 Â g |
| Name of coding element | H Â |
| Colour of coding element | Yellow  |
Environment
| REACh compliance | contains min. 1 SVHC-substance  |
| WEEE classifikation (08/2018) | 5 devices (feed size < 50cm> |
Commercial data
| ECLASS version | ECLASS-9.1 Â |
| ECLASS Reference Feature | 27242604 Â |
| ETIM Version | ETIM-7.0 Â |
| ETIM Reference Group | EG000024Â Â |
