314275
PSSu, electronic module, failsafe, counter, 1 input, absolute encoder SSI encoder, differential signal RS422, resolution 32 Bit, 7 transmission rates, 62.6 - 1500 kHz, for increased environmental requirements.
||
-
-
Secure Shopping
100% Money Back Guarantee.
-
30-DAY RETURNS
30 Days After-sales Return.
-
Worldwide Delivery
Worldwidely Fast Shipping.
General data
| Approval | CE  cULus Listed  TÜV  EAC (Eurasian)  |
| Application range | Failsafe  |
Â
Technical data
Absolute encoder input
| No. of inputs absolute encoder | 1 Â |
| Signal clock output ABS | Differential signal (RS 422) Â |
| Signal data input ABS | Differential signal (RS 422) Â |
| Potent. isol. ABS/per. supply | Yes  |
| Potent. isol. ABS/mod. supply | Yes  |
Environmental data
| Climatic suitability to ... | EN 60068-2-30 Â EN 60068-2-2 Â EN 60068-2-1 Â EN 60068-2-78 Â EN 60068-2-14 Â |
| Ambient temperature standard | EN 60068-2-14 Â |
| Ambient temperature | -40 - 70  °C |
| Storage temperature standard | EN 60068-2-1/-2 Â |
| Climatic suitability standard | EN 60068-2-30 Â EN 60068-2-78 Â |
| Humidity rating | 93 % r. h. at 40 °C  |
| Condensation permitted? | Briefly  |
| Perm. operating height ASL | 5000 m  |
| EMC to standard ... | EN 61000-4-4 Â EN 61000-6-2 Â EN 61000-4-5 Â EN 61000-4-6 Â EN 61000-6-4 Â EN 61000-4-2 Â EN 61000-4-3 Â |
| Vibration to standard ... | EN 60068-2-6 Â |
| Broad band noise to | EN 60068-2-64 Â |
| Acc. shock to standard1 | 15g  |
| Acc. shock to standard2 | Â |
| Clearance & creepage dist. to | EN 60664-1 Â |
| Overvoltage category | II Â |
| Pollution degree clear.&creep. | 2 Â |
| Protection type standard | ENÂ 60529 Â |
| Protection type, mounting | Â |
| Protection type, housing | Â |
| Terminal protection type | Â |
Mechanical data
| Housing material lower section | PC Â |
| Housing material front plate | PC Â |
| Housing material code | PA Â |
| Terminal style | plug-in  |
| Height dimension | 76 Â mm |
| Width dimension | 12.6 Â mm |
| Depth dimension | 60.2 Â mm |
| Net weight | 35 Â g |
| Gross weight | 45 Â g |
| Name of coding element | J Â |
| Colour of coding element | Yellow |
Environment
| REACh compliance | contains min. 1 SVHC-substance  |
| WEEE classifikation (08/2018) | 5 devices (feed size < 50cm> |
Commercial data
| ECLASS version | ECLASS-9.1 Â |
| ECLASS Reference Feature | 27242604 Â |
| ETIM Version | ETIM-7.0 Â |
| ETIM Reference Group | EG000024Â Â |
