328101
PSS u2, electronic module, failsafe, 8 inputs, pulse stretching, discrepancy monitoring, test pulse outputs with 24 V DC 0.25 A, configurable, short circuit-proof, 1-row, terminal block PSS u2 T 16 required (not supplied with the system).
||
-
-
Secure Shopping
100% Money Back Guarantee.
-
30-DAY RETURNS
30 Days After-sales Return.
-
Worldwide Delivery
Worldwidely Fast Shipping.
General data
| Approval | CE  cULus Listed  TÜV  |
| Application range | Failsafe  |
Â
Technical data
Inputs
| Number of digital inputs | 8 Â |
| Signal level at input at 0 | -3 - +5 VDC Â |
| DC voltage at input | 24 V DC Â |
| Input type to ENÂ 61131-2 | 3 Â |
| Software filter time | 0 ms ... 10 ms  |
| Potential isolation input | Yes  |
Test clock outputs
| Number of test pulse outputs | 4 Â |
Environmental data
| Climatic suitability to ... | EN 60068-2-30 Â EN 60068-2-2 Â EN 60068-2-1 Â EN 60068-2-78 Â EN 60068-2-14 Â |
| Ambient temperature standard | EN 60068-2-14 Â |
| Ambient temperature | 0 - 60  °C |
| Storage temperature standard | EN 60068-2-1/-2 Â |
| Climatic suitability standard | EN 60068-2-78 Â |
| Humidity rating | 93 % r. h. at 40 °C  |
| Condensation permitted? | Not permitted  |
| Perm. operating height ASL | 2000 m  |
| EMC to standard ... | EN 61131-2 (Zone B) Â |
| Vibration to standard ... | EN 60068-2-6 Â |
| Acc. shock to standard1 | 150 m/s²  |
| Clearance & creepage dist. to | EN 61131-2 Â UL/IEC 61010-2-201 Â |
| Overvoltage category | II Â |
| Pollution degree clear.&creep. | 2 Â |
| Protection type standard | ENÂ 60529 Â |
| Protection type, mounting | Â |
| Protection type, housing | Â |
Potential separation
| Potential isolation 1 between | Input and module supply  |
| Type of potential isolation 1 | Functional insulation  |
| Potential isolation 2 between | Test pulse o/p and mod. supply  |
| Type of potential isolation 2 | Functional insulation  |
Mechanical data
| Housing material | PC Â |
| Terminal style | plug-in  |
| Height dimension | 110.8 Â mm |
| Width dimension | 12.5 Â mm |
| Depth dimension | 72.5 Â mm |
| Net weight | 37 Â g |
| Gross weight | 46 Â g |
Environment
| REACh compliance | contains min. 1 SVHC-substance  |
| WEEE classifikation (08/2018) | 5 devices (feed size < 50cm> |
Commercial data
| ECLASS version | ECLASS-9.1 Â |
| ECLASS Reference Feature | 27242610 Â |
| ETIM Version | ETIM-7.0 Â |
| ETIM Reference Group | EG000024 |
