401100
PITjog manually operated control device 3 built-in pushbuttons, connection via 10-pin coiled cable with open end.
-
-
Secure Shopping
100% Money Back Guarantee.
-
30-DAY RETURNS
30 Days After-sales Return.
-
Worldwide Delivery
Worldwidely Fast Shipping.
General data
| Approval | CE Â |
| Self-monitored | no  |
Â
Technical data
Electrical data
| Supply voltage (V) | 24 Â V |
| Type of supply voltage U1 | AC/DC Â |
Push button
| Number, pushbutton | 3 Â |
Relay outputs
| Voltage DC1 safety cont. | 24 Â V |
Environmental data
| Ambient temperature | -10 - 55  °C |
| Protection type, housing | Â |
Mechanical data
| Length cable | 5 Â m |
| Material of cable insulation 1 | PUR Â |
| Conductor cross section | 0.14  mm² |
| Housing material | PC-ABS-Blend UL 94V0 Â |
| Height dimension | 341 Â mm |
| Width dimension | 75 Â mm |
| Depth dimension | 60 Â mm |
| Net weight | 837 Â g |
| Gross weight | 951 Â g |
Environment
| RoHS directive | 2011/65/EU Â 2015/863/EU Â |
| RoHS conformity | yes  |
| RoHS exceptions | yes  |
| RoHS except.s acc. to direct. | 6c  |
| REACh compliance | contains min. 1 SVHC-substance  |
| REACh included substances | Lead  |
| %-part of the pollutant | > 0,1 Â |
| CAS No. | 7439-92-1 Â |
| WEEE classifikation (08/2018) | 5 devices (feed size < 50cm> |
Commercial data
| ECLASS version | ECLASS-9.1 Â |
| ECLASS Reference Feature | 27371244 Â |
| ETIM Version | ETIM-7.0 Â |
| ETIM Reference Group | EG000017Â |
