K2E250-AH38-16

NOMINAL DATA

Motor M2E068-DF

Phase	1~	1~	1~
VAC / nominal voltage	115	155	155
Frequency/Hz	50	60	60

Data collection method	ce	ce	ce
Acceptable for approval/standard	CE	CE	UL 2111
min-1 / speed (rpm)	2600	2750	2800
Wattage consumption	100	145	155
Draw of Current / A	0.9	1.25	1.3
Capacitor / pF	8	8	8
Voltage of Capacitor / VDB	250	250	250
Standard of Capacitor	SO(CE)	SO(CE)	UL
Back pressure minimum / Pa	0	0	0
Minimum ambient temperature (in degrees Celsius)	-30	-30	-30
Maximum ambient temperature (in degrees Celsius)	55	55	55
Starting point of current / A	1.78	1.7	1.7

ml = Maximum load, me = Maximum efficiency, and fa = Free air

Customer specification (cs) Customer equipment (ce)

Changes are possible.
