Quality Assurance
OEM Quality Spare Parts.
| Upper level comm. protocol | Ethernet/IP |
|---|---|
| Lower level comm. protocol | IO-Link ver. 1.1 (port class: Class A) |
| I/O Number of ports | 8-port |
| I/O port connector type | M12 |
| I/O Configuration | Digital Input 8-CH, Digital Input/Output 8-CH |
| Power supply port | 7/8 inch, 5-Pin |
| I/O specification | PNP |
| Rated voltage | 24VDC |
| Power consumption | 2.4 W (≤216 W) |
| Supplying current per port | ≤ 2 A/Port |
| Sensor current (US) | ≤ 9 A |
| Dimension | W 66 × H 215 × D 38 mm |
| Material | Zinc Die casting |
| Unit weight (packaged weight) | ≈ 700 g (≈ 900 g) |
| Ambient temperature | -5 to 70℃, Storage: -25 to 70℃ (no freezing or condensation) |
| Ambient humidity | 35 to 75%RH (no freezing or condensation) |
| Protection structure | IP67(IEC standard) |
The exact weight of the cargo you've scheduled will be measured at the QUANTUM office. We will send you an email with a payment link if the weight difference is larger than the shipment amount. The payment link email will include the new weight and the difference amount that must be paid. If you have any queries concerning this procedure, please contact our customer support team at +1-905-625-3500.
