Network | DeviceNet |
---|---|
Type | Digital |
Number Of I/Os_Input | 8-point (PNP) |
Number Of I/Os_Output | 8-point (PNP) |
I/O specification | Voltage: 10-28VDC Current: Input 10mA, Output 0.5A/point(leakage current:max. 0.5mA) |
Module type | Basic unit |
Power supply | 24VDC |
Protection structure | IP20 |
Approval | |
Material | Front case, Body Case: PC, Rubber cap: NBR |
Insulation type | I/O and inner circuit: insulated, DeviceNet and inner circuit: non-insulated, Power and DeviceNet: non-insulated |
Environment_Ambient temperature | -10 to 50ââÆ, storage: -25 to 75? |
Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
Weight | Approx. 140g |
