I/O method | Voltage output |
---|---|
I/O range | -10~10VDC |
Accuracy_Room temp. | ±0.3% F.S. |
Accuracy_Out of room temp. | ±0.6% F.S. |
Load resistance | Min. 5k? |
Status indicator ON conditions | Below -1V or over 1V |
Resolution | 12bit |
Power consumption_ABUS | 5VDC |
Power consumpti_I/O | max. 100mA (max. 0.5W) |
Mounting type | DIN rail mounting |
Insulation resistance | 100M? (at 500VDC I/O to inner circuit: photocoupler insulated, between channels: non-insulated |
Environment_Ambient temperature | -10 to 55ââÆ, storage: -25 to 70ââÆ |
Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
Protection structure | IP20(IEC standard) |
Material | Terminal: polyamide6, Body: modified polyphenylene oxide, Base: polyamide6, poly oxy methylene |
Approval | |
Weight | Approx. 108g (approx. 75g) |
