BS5-P1MD-P
Push Button Type Photomicro Sensor, 0 to 5mm, Dark On, 1M Cable, PNP Output, 12-24 VDC
-
-
Secure Shopping
100% Money Back Guarantee.
-
30-DAY RETURNS
30 Days After-sales Return.
-
Worldwide Delivery
Worldwidely Fast Shipping.
| Operation method | Push Button Type |
|---|---|
| Button operation_Stop position | 5.0±0.4mm |
| Button operation_Output switching position | 4.0±0.5mm |
| Button operation_Operation limit position | Max. 0mm |
| Light source | Infrared LED(940nm) |
| Power supply | 12-24VDC  ±10%(ripple P-P: max. 10%) |
| Current consumption | Max. 35mA |
| Operation load | Max. 3N(Max. 0.3kgf) |
| Operation mode | Dark ON(output ON when button ispushed) |
| Control output | PNP open collector |
| Connection type | Cable type(Ø3, 1m) |
| Environment_Ambient illumination | Fluorescent lamp: Max. 1,000lx(received illumination) |
| Environment_Ambient temperature | -20 to 55℃, storage: -25 to 70℃ |
| Protection structure | IP40 |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| External input_Response | Max. 1ms |
| Material | Case: Polycarbonate + Glass fiber, Button: Polyoxymethylene, Sleeve: SUS304(steel use Stainless 304) |
| Weight | Approx. 50g(approx. 30g) |
