Quality Assurance
OEM Quality Spare Parts.
| Switching voltage | ? 24VDC ? |
|---|---|
| Contact type | Normally Closed |
| Operation distance_OFF?ON | ± 10 mm |
| Operation distance_ON?OFF | ± 20 mm |
| Standard sensing target | Steel plate - a galvanized steel sheet 1.6t |
| Operating frequency | ? 500 Hz |
| Material | Cover/Case: PC (915R) |
| Protection structure | IP67(IEC standard) |
| Approval |  |
| Environment_Ambient temperature | -10 to 65 ?, storage: -10 to 70 ? (no freezing or condensation) |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Insulation resistance | ?1,000M? (at 500VDC megger) |
| Dielectric strength | 500VAC~ 50/60Hz for 1 min. |
| Vibration | 1.5mm amplitude at frequency of 10 to 55Hz (for 1 min) in each X, Y, Z direction for 2 hours |
| Shock | 100m/s² (approx. 10G) in each X, Y, Z direction for 3 times |
| Applied REED SWITCH | Model : ORD324-10-15 (STANDEX MEDER) |
| Weight | ? 107 g (? 147.2 g) |
The exact weight of the cargo you've scheduled will be measured at the QUANTUM office. We will send you an email with a payment link if the weight difference is larger than the shipment amount. The payment link email will include the new weight and the difference amount that must be paid. If you have any queries concerning this procedure, please contact our customer support team at +1-905-625-3500.
