Quality Assurance
OEM Quality Spare Parts.
Out Of Stock
S2SRN-L7Y2ALM
Shark Short Lever Selector Switches, Non-Flush, Illuminated, Ø22/25, 3 Positions maintained Left 90° Right 90°,Yellow, 2 Normal Open, Modular Type, LED 110-220VAC 50/60Hz
-
-
Secure Shopping
100% Money Back Guarantee.
-
30-DAY RETURNS
30 Days After-sales Return.
-
Worldwide Delivery
Worldwidely Fast Shipping.
| Mechanical characteristics_Operation angle | Left 90º , Right 90º |
|---|---|
| Contact block_Electrical specification_Power voltage/current | 110VAC~/10A, 250VAC~/6A |
| LED block_Power supply | 110-220VAC~ 50/60Hz |
| LED block_Current consumption | Max. 20mA |
| Protection structure | IP52 |
| Weight_Mounting hole_Ø22/25 | Approx. 16g |
| Weight_Housing | Approx. 7g |
| Weight_Contact block_Modular type A/B contact | Approx. 10g |
| Weight_LED block_AC voltage type | Approx. 12g |
| Operation type | Short lever 3-position, maintained |
| Color | Yellow |
| Contact block | A contact: 1, B contact: 1 |
| Contact block type | Modular type |
| Environment_Ambient temperature | -15 to 55℃, storage: -25 to 65℃ |
| Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
The exact weight of the cargo you've scheduled will be measured at the QUANTUM office. We will send you an email with a payment link if the weight difference is larger than the shipment amount. The payment link email will include the new weight and the difference amount that must be paid. If you have any queries concerning this procedure, please contact our customer support team at +1-905-625-3500.
