AUTONICS

    Out Of Stock

    S2SRN-LCR2ALM

    Shark Short Lever Selector Switches, Non-Flush, Illuminated, Ø22/25, 3 Positions Spring Return from Left 60° Maintained Right 90°, Red, 2 Normal Open, Modular Type, LED 110-220VAC 50/60Hz


    $16.15 $13.46 / each
    1
    S2SRN-LCR2ALM
    AUTONICS
    FACTORY SEALED

    • Quality Assurance

      OEM Quality Spare Parts.

    • Secure Shopping

      100% Money Back Guarantee.

    • 30-DAY RETURNS

      30 Days After-sales Return.

    • Worldwide Delivery

      Worldwidely Fast Shipping.


    Mechanical characteristics_Operation angleLeft 60º , Right 90º
    Contact block_Electrical specification_Power voltage/current110VAC~/10A, 250VAC~/6A
    LED block_Power supply110-220VAC~ 50/60Hz
    LED block_Current consumptionMax. 20mA
    Protection structureIP52
    Weight_Mounting hole_Ø22/25Approx. 16g
    Weight_HousingApprox. 7g
    Weight_Contact block_Modular type A/B contactApprox. 10g
    Weight_LED block_AC voltage typeApprox. 12g
    Operation typeShort lever 3-position, spring return from left
    ColorRed
    Contact blockA contact: 2
    Contact block typeModular type
    Environment_Ambient temperature-15 to 55℃, storage: -25 to 65℃
    Environment_Ambient humidity35 to 85% RH, storage: 35 to 85% RH
