SFC-R212
Safety Controller, Relay unit, 2 Instantaneous Relay Output, 1PNP Output, Screw Terminal block, 24VDC
-
-
Secure Shopping
100% Money Back Guarantee.
-
30-DAY RETURNS
30 Days After-sales Return.
-
Worldwide Delivery
Worldwidely Fast Shipping.
| Power supply | 24VDC |
|---|---|
| Allowable voltage range | 85 to 110% of rated voltage |
| Power consumption | 4.0W |
| Input | ON: ≥11 VDC ≥ 5mA, OFF: ≤ 5VDC ≤ 1mA |
| Input time | ≥ 50ms, feedback start (manual) : ≥ 100ms |
| Cable | ≤ 100m (≤ 100Ω, ≤ 10nF) |
| Safety output | Relay (A contact) |
| Instantaneous | 2 × |
| Capacity | 240 VAC~ 5A, 30 VDC 5A |
| Life expectancy | Mechanical: ≥ 10,000,000 operations, Malfunction: ≥ 50,000 operations |
| Contact resistance | ≤ 100mΩ |
| Inductive load switching | IEC60947-5-1: AC-15 (230 V/2 A) |
| Conditional short circuit current | 100A |
| Sub output | 1 × PNP transistor: X1 |
| Load current | Max. 100mA |
| Leakage current | ≤ 0.1mA |
| International standards | IEC/EN 61508 (SIL3), IEC/EN 62061 (SILCL3) IEC/EN 60947-5-1, EN ISO 13849-1 (Category 4, PLe) UL listed E249635 |
| Weight | Approx. 80g (approx. 130g) |
