Sensing type | Through-beam type |
---|---|
Light source | Infrared LED(855nm) |
Effective aperture angle(EAA) | Within ± 2.5 ° when the sensing distance is greater than 3 m for both emitter and receiver. |
Sensing distance | Short - Long mode (setting switch or atLightCurtain) |
Short mode | 0.2 to 8 m |
Long mode | 0.2 to 15 m |
Detection capability | Ã 20 mm (hand) |
Sensing target | Opaque |
Protective height | 303 mm |
Number of optical axes | 20 |
Optical axis pitch | 15mm |
Series connection | Max. 4 SET (⤠400 optical axes) |
Power supply | 24 VDC |
Current consumption | Emitter: â¤106mA, receiver: â¤181mA |
Safety related output: OSSD output | NPN or PNP open collector Load voltage : ON - 24 VDC Load current : ⤠300 mA Residual voltage : ⤠2 VDC Load capability: ⤠2.2 ã Leakage current: ⤠2.0 mA Wire resistance of load: ⤠2.7 Ω |
Auxiliary output(AUX 1/2) | NPN or PNP open collector Load voltage: ⤠24 VDC Residual voltage: ⤠2 VDC |
Lamp output(LAMP 1/2) | NPN or PNP open collector Load voltage: ⤠24 VDC |
Protection circuit | Reverse power polarity, reverse output polarity, output short-circuit over-current protection |
Safety-related functions | Interlock (reset hold), external device monitoring (EDM), muting/override, Blanking (fixed blanking, floating blanking), reduced resolution |
General functions | Self-test, alarm for reduction of incident light level, mutual interference prevention |
Others functions | Change of sensing distance, switching to NPN or PNP, external test (light emission stops), auxiliary output (AUX 1, 2), lamp output (LAMP1, 2) |
Synchronization type | Timing method by RS485 synchronous line |
Insulation resistance | Over 20M⦠(at 500VDC megger) |
Noise immunity | The square wave noise (pulse width: 1ã²) by the noise simulator ±240VDC |
Dielectric strength | 1,000VAC 50/60Hz for 1 minute |
Vibration | 10 mm double amplitude at frequency of 5 to 150 Hz, 10 sweeps ni each X, Y, Z direction |
Shock | 250 m/s² (â 25 G), pulse width 6 ms in each X, Y, Z direction for 100 times |
Environment_Ambient illumination | Sunlight: Max. 10,000lx, Incandescent lamp: Max. 3,000lx (received illumination) |
Ambient temperature | -30 to 60 â, storage: -30 ~ 70 â (no freezing or condensation) |
Ambient humidity | 35 to 85 %RH, storage: 35 to 95 %RH (non-freezing or non-condensation) |
Protection structure | IP65, IP67(IEC Standard), IP67G (JEM Standard), IP69K (DIN Standard) |
Material | Case: Aluminum, Front cover and sensing part: Polymethyl methacrylate, End cap: polycarbonate, Power I/O cable and connector cable: polyurethane (PUR) or polyvinyl chloride (PVC), Y type connector cable: polyvinyl chloride (PVC), lamp output cable and series connector cable: polyurethane (PUR), Top / Bottom adjustable bracket and Top / Bottom bracket: SUS304, Side adjustable bracket and Side bracket: nickel plated Zn |
International standards | UL 508, CSA C22.2 No. 14, ISO 13849-1 (PL e, Cat. 4), ISO 13849-2 (PLe, Cat. 4), UL 61496-1 (Type 4, ESPE), UL 61496-2 (Type 4, AOPDs), IEC/EN 61496-1 (Type 4, ESPE), IEC/EN 61496-2 (Type 4, AOPDs), IEC/EN 61508-1~-7 (SIL 3), IEC/EN 62061 (SIL CL 3) |
