Size | DIN W96ÃH96mm |
---|---|
Display method | 4-digit 7-segment LED |
Control method | ON/OFF, P, PI, PD, PID |
Input specification | Thermocouple: K(CA), J(IC), L(IC) RTD: DPt100Ω, Cu50Ω |
Sampling cycle | 100ms |
Control output | Relay (250VAC~ 3A) or SSR drive (12VDC |
Power supply | 100-240VAC~ 50/60Hz |
Display accuracy_RTD | â¢At room temperature(23ºC ± 5ºC):(PV ± 0.5% or ±1ºC, select the higher one) ± 1-digit â¢Out of room temperature range:(PV± 0.5% or ±2ºC, select the higher one)± 1-digit |
Display accuracy_Thermocouple | â¢At room temperature(23ºC ± 5ºC):(PV ± 0.5% or ±1ºC, select the higher one) ± 1-digit â¢Out of room temperature range:(PV± 0.5% or ±2ºC, select the higher one)± 1-digit |
Hysteresis(adjustable sensitivity) | 1 to 100â/â(0.1 to 50.0â/â) variable |
Proportional band | 0.1 to 999.9â/â |
Integral time | 0 to 9999 sec |
Derivative time | 0 to 9999 sec |
Control period | 0.5 to 120.0 sec |
Manual reset | 0.0 to 100.0% |
Environment_Ambient temperature | -10 to 50â, storage: -20 to 60â |
Environment_Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
Insulation type | Double insulation or reinforced insulation(mark: |
Weight | Approx. 254g(approx. 155g) |
