Power supply | 100-240VAC~ 50/60Hz |
---|---|
Power consumption | Max. 8VA |
Display method | 11 segment |
Sampling cycle | 50 / 100 / 250 ms (parameter) |
Option input_CT input | ⢠0.0-50.0 A (primary current measurement range) ⢠CT ratio: 1/1 |
Option input_Digital inputs | ⢠Contact - ON: ⤠2 kΩ |
Control output_Relay | 250VAC~ 3A 1a |
Option output_Alarm | 250VAC~ 3A 1a |
Option output_Trans. | DC 4 - 20 mA (load resistance: ⤠500 Ω, output accuracy: ±0.3% F.S.) |
Option output_Comm. | RS485 |
Control type_Type | ON/OFF, P, PI, PD, PID |
Control type_Multi SV | ⤠4 SV |
Control type_Group PID | ⤠8 group |
Control type_Zone PID | 4 zones |
Control type_ARW | 50 to 200 % |
Hysteresis | ⢠Thermocouple, RTD: 1 to 100 (0.1 to 100.0) â/â ⢠Analog: 1 to 100 digit |
Dielectric strength | Between primary terminal and case: 3,000 VAC~ 50/60 Hz for 1 min |
Vibration | 0.75 mm amplitude at frequency of 5 to 55 Hzin each X, Y, Z direction for 2 hours |
Relay life cycle_Mechanical | ⢠OUT1/2: ⥠5,000,000 operations ⢠AL1/2/3/4/5/6: ⥠20,000,000 operations |
Relay life cycle_Electrical | ⢠OUT1/2: ⥠200,000 operations ⢠AL1/2/3/4/5/6: ⥠100,000 operations |
Insulation resistance | ⥠100 MΩ (500 VDC megger) |
Insulation type | Double insulation or reinforced insulation (mark: , dielectric strength between the measuring input part and the power part: 3 kV) |
Noise immunity | ±2 kV square shaped noise by noise simulator (pulse width: 1 ã²) R-phase, S-phase |
Memory Protection | â 10 years (non-volatile semiconductor memory type) |
Ambient temperature | -10 to 50 â, storage: -20 to 60 â (no freezing or condensation) |
Ambient humidity | 35 to 85%RH |
Protection structure | IP65 (Front panel, IEC standards) |
Loader port | Front side |
Accessories | Bracket |
Weight | 301 g |
